Classic Black Single Rail Bypass Kit BP02 | Sliding Door Hardware Melbourne
Classic Black Single Rail Bypass Kit BP02
Sliding Door Hardware Melbourne
Classic Black Single Rail Double Door Bypass System BP02 - Made of iron and POM, black powder coated, comes in a complete kit with constructions, easy to install.
You will need to consider the minimum 160mm overlaps for the two doors when choosing the track length;
|Material||Iron & POM|
|For Door Weight||Up to 120kg|
|For Door Thickness||35-45mm|
|Track||1 piece or 2 pieces(over 2m)|
Don't know what size you need?
Usually the track's length needs to be the opening width plus the door's width
Still not sure what size you need? Contact us anytime
150mm minimum space required above the door;
We can do installations for VIC customers, contact us for more details;
To install this system, the wall must be strong enough. For plaster wall we recommend to attach a piece of timber board (For example, 2m rail, we use 2000x42x18mm timber) on the wall first, then screw the rail on the timber board;
Check our Blog Posts ''Latest Cases of Barn Door Installation''
All products shown on this web site are subject to Aubarndoors’ stocks in Melbourne, Australia;
This product only contains the hardware kit, the barn doors and handle need to be purchased from us separately;
Due the COVID-19 in Australia, the whole freight industry is experiencing high volume of deliveries and delays, please allow some extra days for the freight to be delivered.
Currently the freight deliveries may take much longer time than normal, we can not cancel the order or provide any refund until the courier company has deemed the freight as lost.
If you have any question, please feel free to contact us at:
P: 1300 227 636
M: 0455 663 777
